125K EHV-5G-US-PLUS Solis PV Inverter 125kW 600V 3-Phase

Solis 125K EHV-5G-US-PLUS — 125kW / 600V | 3-Phase PV String Inverter

The Solis 125K EHV-5G-US-PLUS is a high-efficiency 125kW, 600V three-phase string inverter from the 5th Generation EHV series, designed for commercial and utility-scale solar installations. With up to 14 MPPTs, AFCI protection, and UL 1741-SB certification, it delivers safe, reliable, and cost-effective performance for demanding grid-tied applications in North America.

Key Features

• 125kW Output / 600V DC — commercial-scale power density in a single unit
• Up to 14 MPPTs, 99.0% Max Efficiency — 75 MPPT/MW tracking density for maximum energy harvest
• >1.5 DC/AC Ratio Support — lower starting voltage and longer daily generation time
• Compatible with 500W+ Bifacial Modules — optimized for next-generation high-power panels
• AFCI Protection — proactively reduces arc-fault fire risk
• Fuse-Free Design — safe, maintenance-free DC input architecture
• Built-in Nighttime PID Recovery — protects and restores module performance over time
• Smart I-V Curve Scan — intelligent string monitoring and remote firmware upgrades
• Aluminium Wire & “Y” Connector Support — reduces BOS costs and simplifies DC wiring
• DC Energy Storage Reserve — future-ready for hybrid storage integration
• Type 4X / C5 Anti-Corrosion — rated for harsh outdoor environments
• 10-Year Warranty — dimensions: 1170mm × 770mm, weight: 108.8kg

Certifications

• UL 1741-SA and UL 1741-SB
• IEEE 2030.5 (CSIP)

Compatible With

• 500W+ bifacial PV modules
• SolisCloud remote monitoring platform
• Optional Power Line Communication (PLC) module
• DC-side “Y” connector configurations

Contact us for custom pricing. Ships from Thunder Battery — Canada's trusted battery dealer.
