CIP136100010 MEGA-fuse 100A/32V (pack of 5)

Victron Orion-Tr 24/24-12A Isolated DC-DC Converter

Charging a second 24V battery bank from your main 24V system — with complete electrical isolation between them — is exactly what the Victron Orion-Tr 24/24-12A is built for. At 280W continuous output with full galvanic isolation, it keeps your primary and auxiliary 24V banks completely separate, preventing ground loops and protecting sensitive electronics. Whether you're running a dual-bank marine installation, a large RV, or an off-grid system with redundant 24V storage, this converter delivers reliable, isolated charging.

Key Features

• 280W continuous output — 24V input to isolated 24V output at 12A
• Galvanic isolation — eliminates ground loops, protects sensitive electronics
• Wide input voltage range — compatible with 24V lead-acid and lithium battery systems
• Adjustable output voltage — fine-tune to match your battery charging requirements
• High efficiency — up to 93%, minimal heat generation
• Robust housing — suitable for demanding marine, RV, and vehicle environments
• Remote on/off — easy integration with system controllers

Specifications

• Input voltage: 20–35V DC
• Output voltage: 24V (adjustable)
• Output current: 12A
• Output power: 280W
• Isolation: Yes (galvanic)
• Efficiency: Up to 93%
• Operating temperature: -40°C to +60°C

Ideal For

• Dual 24V battery bank systems in marine vessels and RVs
• Isolating primary and auxiliary 24V battery banks
• Off-grid solar systems with redundant 24V storage
• Commercial vehicles requiring isolated 24V auxiliary charging

Ships from Thunder Battery — Canada's trusted Victron Energy dealer.
