ORI110243610 Orion 110/24-15A (360W) Isolated DC-DC converter

Victron Orion-Tr 12/12-30A Isolated DC-DC Converter

When your dual-battery system demands serious charging current with complete electrical isolation, the Victron Orion-Tr 12/12-30A delivers. At 360W continuous output, it charges your house or auxiliary 12V battery bank from your starter battery at 30A — with full galvanic isolation to prevent ground loops and protect sensitive electronics. Whether you're running a large marine house bank, a heavy-duty RV setup, or a commercial vehicle auxiliary system, this converter keeps everything charged and protected.

Key Features

• 360W continuous output — 12V input to isolated 12V output at 30A
• Galvanic isolation — eliminates ground loops, protects sensitive electronics
• Wide input voltage range — compatible with 12V lead-acid and lithium battery systems
• Adjustable output voltage — fine-tune to match your battery charging requirements
• High efficiency — up to 93%, minimal heat generation
• Robust housing — suitable for demanding marine, RV, and vehicle environments
• Remote on/off — easy integration with system controllers

Specifications

• Input voltage: 9.5–17V DC
• Output voltage: 12V (adjustable)
• Output current: 30A
• Output power: 360W
• Isolation: Yes (galvanic)
• Efficiency: Up to 93%
• Operating temperature: -40°C to +60°C

Ideal For

• High-current dual-battery charging in marine vessels and RVs
• Isolating starter and large house battery banks
• Commercial vehicle auxiliary battery systems
• Off-grid vehicles and camper vans with high power demands

Ships from Thunder Battery — Canada's trusted Victron Energy dealer.
