ORI121210110R Orion-Tr Smart 12/12-9A (110W) Isolated DC-DC Charger

Victron Orion-Tr 24/12-30A Isolated DC-DC Converter

When your 24V system needs to power serious 12V loads — with complete electrical isolation — the Victron Orion-Tr 24/12-30A is the converter for the job. At 360W continuous output, it steps down 24V to 12V at 30A with full galvanic isolation, protecting your electronics from ground loops and delivering clean, stable 12V power for demanding loads. Whether you're running a large marine installation, a heavy-duty RV, or a commercial vehicle with high 12V power demands, this converter handles it reliably.

Key Features

• 360W continuous output — 24V input to isolated 12V output at 30A
• Galvanic isolation — eliminates ground loops, protects sensitive electronics
• Wide input voltage range — compatible with 24V lead-acid and lithium battery systems
• Adjustable output voltage — fine-tune to match your 12V load requirements
• High efficiency — up to 93%, minimal heat generation
• Robust housing — suitable for demanding marine, RV, and vehicle environments
• Remote on/off — easy integration with system controllers

Specifications

• Input voltage: 20–35V DC
• Output voltage: 12V (adjustable)
• Output current: 30A
• Output power: 360W
• Isolation: Yes (galvanic)
• Efficiency: Up to 93%
• Operating temperature: -40°C to +60°C

Ideal For

• High-draw 12V accessories in 24V marine and RV systems
• Commercial vehicles with 24V systems requiring high-current 12V power
• Off-grid solar systems with 24V battery banks and large 12V loads
• Industrial and telecom 12V auxiliary power

Ships from Thunder Battery — Canada's trusted Victron Energy dealer.
