ORI122408020 Orion 12/24-8 DC-DC converter IP20

Victron Orion-Tr 12/48-2.5A Isolated DC-DC Converter

Need to power 48V equipment from a 12V battery bank — with complete electrical isolation? The Victron Orion-Tr 12/48-2.5A steps up from 12V to 48V at 120W continuous output, with full galvanic isolation to protect your electronics and eliminate ground loops. Compact and efficient, it's ideal for integrating 48V loads into 12V off-grid, marine, or vehicle systems where isolation is essential.

Key Features

• 120W continuous output — 12V input to isolated 48V output at 2.5A
• Galvanic isolation — eliminates ground loops, protects sensitive electronics
• Wide input voltage range — compatible with 12V lead-acid and lithium battery systems
• Adjustable output voltage — fine-tune to match your 48V load requirements
• High efficiency — up to 93%, minimal heat generation
• Compact, robust housing — easy to install in tight spaces
• Remote on/off — simple integration with system controllers

Specifications

• Input voltage: 9.5–17V DC
• Output voltage: 48V (adjustable)
• Output current: 2.5A
• Output power: 120W
• Isolation: Yes (galvanic)
• Efficiency: Up to 93%
• Operating temperature: -40°C to +60°C

Ideal For

• Powering 48V equipment from 12V battery systems
• Lithium battery system integration with mixed voltages
• Off-grid solar systems with 12V battery banks and 48V loads
• Marine and RV multi-voltage installations

Ships from Thunder Battery — Canada's trusted Victron Energy dealer.
