ORI481238120 Orion-Tr Smart 48/12-30A (360W) Isolated DC-DC charger

Victron Orion-Tr Smart 48/12-30A (360W) Isolated DC-DC Charger

The Victron Orion-Tr Smart 48/12-30A is an intelligent isolated DC-DC charger that steps down 48V input to 12V output at 30A (360W). Designed for dual-battery systems requiring galvanic isolation, it is ideal for off-grid, marine, and industrial applications where a 48V primary source needs to charge a 12V secondary battery bank. Built-in Bluetooth and smart adaptive charging make it a powerful addition to any Victron system.

Key Features

• 360W output power — efficient 48V to 12V step-down charging
• 30A output current — fast charging for 12V secondary battery banks
• Isolated output — galvanic isolation protects sensitive electronics
• Built-in Bluetooth — configure and monitor via VictronConnect app
• Smart adaptive charging — multi-stage charging for lithium and lead-acid batteries

Specifications

• Input voltage: 48V
• Output voltage: 12V (adjustable)
• Max output current: 30A
• Max output power: 360W
• Communication: Bluetooth (VictronConnect)
• Protection: reverse polarity, over-temperature, short circuit

Ideal For

• Off-grid solar systems with 48V main and 12V auxiliary banks
• Marine systems requiring 12V loads from a 48V source
• Industrial and commercial 48V systems with 12V accessories
• Systems requiring galvanic isolation between voltage levels

Ships from Thunder Battery — Canada's trusted Victron Energy dealer.
